101016 Three-Chamber Gas-Diffusion Cell

Product overview

Model 101016 is a compact three-chamber gas-diffusion cell. The catalog gives a 5 × 20 mm chamber dimension and 7 mm anode-to-cathode spacing. This version has no flooding observation window, so specify whether optical access to the gas-diffusion region is necessary before selecting the configuration.

Specifications & ordering details

Use these parameters to define your requirement. The quotation confirms the exact supplied specification.

Material / system	PEEK
Catalog model	101016
Body material	PEEK
Chamber dimension	5 × 20 mm
Reaction area	1 cm²
Anode-to-cathode spacing	7 mm
Flooding observation window	Not equipped
Active area and flow-field design	Specify with your requirement.
Plate / current-collector materials	Specify with your requirement.
Connections and included accessories	Specify with your requirement.

Research applications

Three-chamber electrolysis
Gas-diffusion electrode evaluation
Small-area flow-cell research

Before you order

Confirm the 1 cm² reaction geometry.
Specify the membrane, GDE and fluid interfaces.
Select a window-equipped model if flooding observation is required.

Product documents

View the source catalog for this offering. Share your grade, model and application to request the relevant specification or material documentation.

View Electrochemistry, Flow & MEA Systems — page 38 ↗Download PDF

Selection questions

What should a custom enquiry include?

For 101016 Three-Chamber Gas-Diffusion Cell, provide the active area, sample or electrode geometry, materials, interfaces and the operating conditions. Include drawings and identify every component in the assembly scope.

Are electrodes, membranes and accessories included?

Specify the parts required. Hardware, membranes, electrodes, gaskets, fittings and instruments should be identified separately in the quotation.
